常用尺寸 |
20英寸（508mm左右） |
亦可根据 需要进行定做 |
| 40英寸（1016mm左右） | ||
| 60英寸（1524mm左右） | ||
| 常用精度 |
1μm、3μm、10μm、 20μm、40μm、 50μm、60μm、100μm |
可根据工况随时调整 |
|
过滤面积 |
20英寸--4-5㎡ | |
| 40英寸--8-10㎡ | ||
| 60英寸--12-15㎡ | ||
| 单支过滤流量 | 20英寸--10m³/H | 5μm精度条件下 |
| 40英寸--20m³/H | ||
| 60英寸--30m³/H | ||
|
过滤形式 |
内进外出 | 不同形式的过滤进水方向不同 |
| 外进内出 | ||
| 初始压差 | 0.02MPa | |
| 更换压降 | 0.25Mpa | |
| 最大压降 | 0.35Mpa | |
| 最高使用温度 | 80℃ | |
| HFU620UY010 | HFU620UY050 | HFU620UY100 | HFU620UY200 | HFU620UY400 | HFU620UY700 | |
| HFU620GF010 | HFU620GF050 | HFU620GF100 | HFU620GF200 | HFU620GF400 | HFU620GF700 | HFU620GF01000 |
| HFU640UY010 | HFU640UY050 | HFU640UY100 | HFU640UY200 | HFU640UY400 | HFU640UY700 | HFU640UY01000 |
| HFU640GF010 | HFU640GF050 | HFU640GF100 | HFU640GF200 | HFU640GF400 | HFU640GF700 | HFU640GF01000 |
| HFU660UY010 | HFU660UY050 | HFU660UY100 | HFU660UY200 | HFU660UY400 | HFU660UY700 | HFU660UY01000 |
| HFU660GF010 | HFU660GF050 | HFU660GF100 | HFU660GF200 | HFU660GF400 | HFU660GF700 | HFU660GF01000 |
| HF40PP001A01 | HF40PP001B01 | HF40PP001C01 | HF40PP001D01 | HF40PP002A01 | HF40PP002B01 | HF60PP025C01 |
| HF40PP002C01 | HF40PP010B01 | HF40PP025A01 | HF40PP040D01 | HF60PP001C01 | HF60PP005B01 | HF60PP025B01 |
| HF40PP002D01 | HF40PP005A01 | HF40PP005B01 | HF40PP005C01 | HF40PP005D01 | HF40PP010A01 | HF60PP025A01 |
| HF40PP010C01 | HF40PP010D01 | HF40PP015A01 | HF40PP015B01 | HF40PP015C01 | HF40PP015D01 | HF60PP015D01 |
| HF40PP025B01 | HF40PP025C01 | HF40PP025D01 | HF40PP040A01 | HF40PP040B01 | HF40PP040C01 | HF60PP015C01 |
| HF40PP070A01 | HF40PP070B01 | HF40PP070C01 | HF40PP070D01 | HF60PP001A01 | HF60PP001B01 | HF60PP015B01 |
| HF60PP001D01 | HF60PP002A01 | HF60PP002B01 | HF60PP002C01 | HF60PP002D01 | HF60PP005A01 | HFU620UY01000 |
| HF60PP005C01 | HF60PP005D01 | HF60PP010A01 | HF60PP010B01 | HF60PP010C01 | HF60PP010D01 | |
| HF60PP015A01 | HF60PP025D01 | HF60PP070C01 | HF60PP070D01 | HF60PP070A01 | HF60PP070B01 |
